Streckkodsläsare Vega 1020 Bluetooth

SCANTECH VEGA 1010 Bluetooth

SCANTECH VEGA 1020 Bluetooth

The VEGA handheld bar code scanner series, with an extensive range of models, represents the new style in handheld bar code scanning.
It is a modern and ergonomically designed scanner which offers an outstanding reading performance. The VEGA scanners are available with a number of interfaces, which offers a wide range of possibilities and solution for every Point of Sale environment


Reading distance up to 44 cm
Scan speed of 200 scans / second linear mode
56 images / second in 2D mode
Guarantees an outstanding scan performance
Reads all common 1D and 2D barcodes regardless of orientation
Wireless (Bluetooth) and all common interfaces

Charging cradle
Flexi Stand


Reading Indicator: Beeper and LED
Scan Rate in 1D mode: 200 scans/second &
move this spec to Scanner Characteristics
Scan Rate in 2D mode: 56 images/second &
move this spec to Scanner Characteristics
Battery: Lithium-ion 3.7 V / 1400 mA
Scan times per Battery full charge: Reads
per charge 10.000 reads
Interfaces: RS232, USB (HID KBW), KBW
Sensor: Area Imager CMOS
Light source: 650 nm red LED
Depth of field: 440 mm
Resolution: 0.125 mm (5mil) @ code 39
Operating Temperature: 0°C - 50°C
Relative Humidity: 20% to 85% (non-condensing)
Drop Resistance: Withstands multiple drops of 1.0 m
on concrete surface
Bluetooth Module: Bluetooth V2.0 Standard
Bluetooth Distance Range: Class 1 up to 100 m /
330 ft (open air)
Regularity of Compliance: CE, FCC, and RoHs
Scanner Dimension: 186.8 (L) x 81.6 (W) x 63.9 (H) mm,
approx. 195 gr (incl. cable)
Cradle Dimension: 123.9 (L) x 120 (W) x 71.4 (H) mm,
approx. 145 gr (incl. cable)
