SCANTECH VEGA 1010 Bluetooth

SCANTECH VEGA 1010 Bluetooth

The VEGA handheld bar code scanner series, with an extensive range of models, represents the new style in handheld bar code scanning.
It is a modern and ergonomically designed scanner which offers an outstanding reading performance. The VEGA scanners are available with a number of interfaces, which offers a wide range of possibilities and solution for every Point of Sale environment.


Reading distance up to 44 cm
Scan speed of 200 scans / second linear mode
56 images / second in 2D mode
Guarantees an outstanding scan performance
Reads all common 1D and 2D barcodes regardless of orientation
Wireless (Bluetooth) and all common interfaces

Charging cradle
Flexi Stand


Scanner Dimension: 186.8(L)x81.6(W)x63.9(H)mm,
approx. 195gr (incl. cable)
Cradle Dimension: 123.9(L)x120(W)x71.4(H)mm,
approx. 145gr (incl. cable)
Reading Indicator: Beeper and LED
Battery: Lithium-ion 3.7 V/1400mA
Scan times per Battery
full charge Reads per charge: 30.000 reads
Interfaces: RS232, KBW, USB
(HID and COM port)
Sensor / Light Source: Linear CCD/639nm red LED
Depth of field: 270 mm
Resolution: 0.1 mm (4mil) @ PCS 0.9
Scan Rate: 700 scans / second ± 10%
Bluetooth Module: Bluetooth V2.0 Standard
Bluetooth Distance Range: Class 1 up to 80 m
line of sight in open space
Operating Temperature: 0°C - 50°C
Storage Temperature: -20°C - 60°C
Relative Humidity: 20% to 95%(non-condensing)
Withstands multiple drops of: 1.0 m on concrete surface
Regularity of Compliance: CE, FCC, and RoHs
Scanner Dimension: 186.8 (L) x 81.6 (W) x
63.9 (H)mm, approx. 195gr
(incl. cable)
Cradle Dimension: 123.9 (L) x 120 (W) x
71.4 (H)mm, approx. 145gr
(incl. cable)
